18K COOLING + HEATING - 208/230V LIGHT COMMERCIAL FLOOR-CEILING SYSTEM – 22.3 SEER2

18K COOLING + HEATING - 208/230V LIGHT COMMERCIAL FLOOR-CEILING SYSTEM – 22.3 SEER2

SKU: CPP3F-18CD

BARCODE: FPA3-18CD(I) + CPP3-18CD(O)

PRODUCT TYPE: Floor/Ceiling Units

Product Catalog

View full details
Refrigerant Type: R454B
SEER2: 22.3
EER2: 12.5
HSPF2-4: 10.4
HSPF2-5: 8
Max. Allowable Piping Length (ft): 98.40
Min. Allowable Piping Length (ft):
Max. Allowable Elevation Differences (ft): 65.60
Min. Power Supply Wire Size (AWG):
Min. Inter-Connecting Wire Size (AWG): 14*4, Stranded
Piping Size: 1/4"- 1/2"
Operating Mode: Heating and Cooling
Outdoor Ambient Temperature: -13°F
Indoor Unit Net/Gross Weight (lbs.): 58.42/70.55
Outdoor Unit Net/Gross Weight (lbs.): 92.59/100.31

Features

• 18,000 BTU Cooling and Heating Capacity
• 208/230V, 60Hz, Single-Phase Power Supply
• 22.3 SEER2 and 12.5 EER2
• R454B Refrigerant
• Outdoor Heating and Cooling Operation Down to -13°F
• Floor/Ceiling Indoor Unit with Two Installation Styles
• 3D Airflow
• Humidity Sensor
• Refrigerant Leakage Detection Sensor
• Fan Speed Stages from 1–100%
• Wi-Fi Capable via Wi-Fi USB or Compatible Wired Control
• Multiple Control Options, Including Wireless Remote and Third-Party 24V Thermostat

Specifications

Unit Size - Inches (W x D x H):

Indoor - 42.05x26.57x9.25
Outdoor - 35.04x13.46x26.50

Voltage: 208/230V

Air Flow - CFM (Hi / Mi / Lo):

Indoor - 548.24/485.29/420.59
Outdoor - 1764.7

Tonnage: 1.5

dB(A) Noise Level (Hi / Mi / Lo):

Indoor - 43/40/32
Outdoor - 57

Heat Capacity (BTU): 18,000

Cooling Capacity (BTU): 18,000

Placement: Light Commercial Applications

Breaker Size (A): Indoor: 15
Outdoor:20

Factory Refrigerant Charge (ft):

Refrigerant Adjustment Factor (oz. per ft): 0.16

Drain Pipe Size (in):
