• 24,000 BTU Cooling Capacity
• 25,000 BTU Heating Capacity
• 208/230V, 60Hz, Single-Phase Power Supply
• 19.0 SEER2 and 12.5 EER2
• R454B Refrigerant
• Outdoor Heating and Cooling Operation Down to -13°F
• Ducted Fan Coil for Horizontal or Vertical Installation
• Four Static Pressure Settings
• Built-In Condensate Pump
• Optional Constant Airflow
• I-Clean Function
• Refrigerant Leakage Detection Sensor
• Fan Speed Stages from 1–100%
• Wi-Fi Capable via Wi-Fi USB or Compatible Wired Control
• Compatible with Third-Party 24V Thermostats

Unit Size - Inches (W x D x H):

Indoor - 39.37/29.53/9.65
Outdoor - 37.24/16.14/31.89

Voltage: 208/230V

Air Flow - CFM (Hi / Mi / Lo):

Indoor - 706.3/618.0/500.3
Outdoor - 2,236.7

Tonnage: 2

dB(A) Noise Level (Hi / Mi / Lo):

Indoor - 40/38/35.5
Outdoor - 60

Heat Capacity (BTU): 24,000

Cooling Capacity (BTU): 25,000

Placement: Light Commercial Applications

Breaker Size (A): 15/25

Factory Refrigerant Charge (ft):

Refrigerant Adjustment Factor (oz. per ft): 0.16

Drain Pipe Size (in):
