LOW AMBIENT: Capable of producing comfortable heating and cooling to outdoor ambient temperatures as low as 5°F.
MANUAL POWER SWITCH: Power unit ON/OFF using button located at the evaporator.
INTERACTIVE DISPLAY SHOWS: – Error codes based on system failure.
– Service codes if your filter needs cleaning.
– Error code if refrigerant leak is detected.
– When unit goes into auto defrost.
SELF-DIAGNOSIS: Unit will shut down and go into protection mode if it detects abnormalities. The display will show an error code.
BYPASS MODE: Unit will continue to operate if a non-critical component fails, such as a sensor.
2-WAY DRAINING OPTION: Ability to place drain hose on left or right hand side of evaporator allows for flexible installation.
3 DIRECTIONAL AIRFLOW: Air flow is directed so that it reaches more surface area including the corners of the room.
MUTE OPERATION: Silence from the Remote Control.
FOLLOW ME FUNCTION: Remote Control has a sensor built in. In this mode, the unit will sense the temperature at the Remote Control instead of at the indoor unit for the set temperature.
CONTROLS: Wired Controls and Wi-Fi Control – (optional).

Unit Size - Inches (W x D x H):

Indoor - 49.57x11.14x14.25
Outdoor - 37.24x16.14x31.89

Voltage: 208/230V

Air Flow - CFM (Hi / Mi / Lo):

Indoor - 652.94/447.06/329.41
Outdoor - 2235

Tonnage: 3

dB(A) Noise Level (Hi / Mi / Lo):

Indoor - 54/45/40
Outdoor - 61.5

Heat Capacity (BTU): 36000

Cooling Capacity (BTU): 36000

Placement: Residential and Commercial Applications

Breaker Size (A): 35

Factory Refrigerant Charge (ft): 25

Refrigerant Adjustment Factor (oz. per ft): 0.32

Drain Pipe Size (in): 3/4"
