60K LCM5 MULTI-POSITION AIR HANDLER - UP TO 15.2 SEER2
60K LCM5 MULTI-POSITION AIR HANDLER - UP TO 15.2 SEER2
SKU: LCM5-60-15
PRODUCT TYPE: Air Handlers
Unit Size - Inches (W x D x H):
22x24x54-1/2
Voltage:
208-230v
Air Flow - CFM (Hi / Mi / Lo):
1930/2320/2560
Tonnage:
5
dB(A) Noise Level (Hi / Mi / Lo):
55
SEER2:
Up to 15.2
EER:
Up to 12
Heat Capacity (BTU):
Field Installed Heater Kits are Optional: 5/ 7.5/ 10/ 15/ 20KW
Cooling Capacity (BTU):
60000
Placement:
Indoor Multi-Position Air Handler Unit
Outdoor Unit Net/Gross Weight (lbs.):
159
Features
Features
• Factory sealed cabinet helps achieve 2% or less on leakage rate.
• Horizontal and vertical condensate pans are standard.
• Blower wheel and coil can easily slide out for easier maintenance.
• Field Installed Heater Kits are OPTIONAL: 5/ 7.5/ 10/ 15/ 20KW.
• Multi-speed, constant torque, ECM blower motor.
• 2-stage fan control.
• AHRI/ETL Certified.
• Mobile Home Certification.
![LCM](http://www.ar-supply.com/cdn/shop/products/PLATLC_2_de4df36e-bf46-4c83-be38-ff2c9ebeae81.jpg?v=1673992278&width=1445)
Free Lift Gate
*This product qualifies for Free Lift Gate Service. Items over 100lbs normally ship via semi-truck. Select this service if you need the product lowered to the ground curbside.LCM5 COMBINATIONS
![](https://cdn.shopify.com/s/files/1/0659/0968/6501/files/Bar5-Series-SEER2-Correo-1_4__Page_15_-_Copy.png?v=1703080835)
![](https://cdn.shopify.com/s/files/1/0659/0968/6501/files/Bar5-Series-SEER2-Correo-1_3__Page_14.png?v=1703080861)
