• 9,000 BTU Cooling Capacity
• 10,000 BTU Heating Capacity
• 208/230V, 60Hz, Single-Phase Power Supply
• 19.5 SEER2 and 12.8 EER2
• R454B Refrigerant
• Outdoor Heating and Cooling Operation Down to -13°F
• Ducted Fan Coil for Horizontal or Vertical Installation
• Four Static Pressure Settings
• Built-In Condensate Pump
• Optional Constant Airflow
• I-Clean Function
• Refrigerant Leakage Detection Sensor
• Fan Speed Stages from 1–100%
• Wi-Fi Capable via Wi-Fi USB or Compatible Wired Control
• Multiple Control Options, Including Wireless Remote and Third-Party 24V Thermostat

Unit Size - Inches (W x D x H):

Indoor - 27.56x19.92x7.87
Outdoor - 30.12x11.93x21.85

Voltage: 208/230V

Air Flow - CFM (Hi / Mi / Lo):

Indoor - 352.94/282.35/176.47
Outdoor - 1294.1

Tonnage: 0.75

dB(A) Noise Level (Hi / Mi / Lo):

Indoor - 34/32.5/29
Outdoor - 54

Heat Capacity (BTU): 10000

Cooling Capacity (BTU): 9000

Placement: Light Commercial Applications

Breaker Size (A): 15

Factory Refrigerant Charge (ft): 25

Refrigerant Adjustment Factor (oz. per ft): 0.16

Drain Pipe Size (in):
