Heat Pump / Conventional
1 Heat, 1 Cool Conventional
2 Heat, 1 Cool Heat Pump
Battery or Hardwire
Non-Programmable
4 sq. inch display
Blue backlight
Glow in the dark light button
Easy access battery compartment
Electric or Gas configurable
Separate heating cooling swing (cycle rate) adjustments including 2nd stage adjustments
Filter change indicator (select-able on or off)
5 minute compressor delay protection (select-able on or off)
Room temperature calibration adjustments
Simple private label badge system
Easy wire color coded terminal blocks
Universal sub-base
Mounts on wall or junction box
Battery or 24V power
5 year warranty
The display range of temperature
41˚F to 95˚F (5˚C to 35˚C)
The control temperature range
44˚F to 90˚F (7˚C to 32˚C)
Load rating
1 amp per terminal, 1.5 amp maximum all terminals combined
Display accuracy
± 1 °F
Swing (cycle rate or differential)
Heating is adjustable from 0.2°F to 2.0°F - Cooling is adjustable from 0.2°F to 2.0°F
Power source
18 to 30 VAC, NEC Class II, 50/60 Hz for hardwire (common wire)
Battery power from 2 AA Alkaline batteries
Operating ambient
32° to +105° (0° to + 41°C)
Operating humidity
90% non-condensing maximum
Dimensions of thermostat
4.7"W x 4.4"H x 1.1"D
