CWM 36K WALL MOUNTED CWM5 ECM AIR HANDLER - FRONT OR BOTTOM RETURN - UP TO 15.2 SEER2
CWM CWM
10 Year Compressor Warranty10 Year Parts Warranty

COMFORTSTAR

TECH SUPPORT APP catalog link catalog link

36K WALL MOUNTED CWM5 ECM AIR HANDLER - FRONT OR BOTTOM RETURN - UP TO 15.2 SEER2

36K WALL MOUNTED CWM5 ECM AIR HANDLER - FRONT OR BOTTOM RETURN - UP TO 15.2 SEER2

SKU: CWM5-36-15

PRODUCT TYPE: Air Handlers

Free Lift Gate

Expedited Shipping

System Gross Weight: 119 (lbs.)
Combination Table
View full details
Refrigerant Type: R410a
Unit Size - Inches (W x D x H): 22x19x39-1/2
Voltage: 208-230V
Air Flow - CFM (Hi / Mi / Lo): 1600/1870/1960
Tonnage: 3
dB(A) Noise Level (Hi / Mi / Lo): 54
SEER2: Up to 15.2
EER: Up to 12
Operating Mode: Cooling Only
Heat Capacity (BTU): Electric Heat Kit for Field Installation (5kw, 8kw and 10kw)
Cooling Capacity (BTU): 36000
Placement: Indoor Wall Mount Front or Bottom Return Air Handler Unit
Outdoor Unit Net/Gross Weight (lbs.): 97/119

Features

• Direct drive multi speed motor
• Multi speed ECM motor
• Thermoplastic drain pan with bottom primary
and secondary drain connections.
• Built-in filter rack.
• Wall-hanging bracket provided.
• Front or bottom return available.
• Optional heating elements of 5kW, 8kW, and 10kW.
• All aluminum coil.
